Total Area Comfort Heating
Spot heating locates the heater above the areas
you are located so the air in the entire room is not heated. Infrared heats
objects not air, so you are kept warmer even in a relatively cold room. Some
heaters use a quartz glass heating element and some use a metal sheath tubular
element. Metal heaters last longer, do not emit light, and are not as subject to
damage from environmental factors, shock and impact. The advantage of quartz is
quick heat up (seconds) and a higher efficiency of infrared.
|
Comfort Heating for a
large gazebo.
 |
In electric Infrared heating for ‘Total
Area’ heat design, the
actual fixture layout parallels closely the approach used in a general
lighting system, but without as much permissible latitude. The allowable
range of air temperature people accept as "comfortable" is
very limited. Deviations of a few degrees from the preferred comfort
temperature greatly affect a feeling of being too warm or too cold. For
this reason, assumptions or rough approximations of critical factors in
an indoor total heating system design must be minimized.
In electric infrared
heating systems, it is important to know that air
temperatures can be lower than temperatures with conventional heating
systems, while giving the same degree of comfort to the occupants. The
reason is that much of the heating affect on the occupants comes
directly from the radiant energy produced by the heating elements. The
infrared system also makes the temperature of the floor and surfaces
higher than the surrounding air temperature.
The function of an electric
infrared ‘Total Area’ heating
system is to supply the right amount of heating where needed
to maintain a constant desired comfort level. An effective heating
system brings the room surfaces and air up to temperature and holds them
constant despite changes in outside air temperature or variations in
heat losses. If the infrared equipment is carefully selected and
properly installed (to project heat downward in a uniform distribution
pattern over the floor area), excellent ‘Total
Area’ heating efficiency can be expected. |
 |
Fostoria OCH-SERIES
Outdoor Trimline
Quartz Tube Comfort Spot Heating Assemblies. Overhead "Spot" or "Zone"
heating applications. Nearly instantaneous heat-up and can provide heat
for specific areas within a large area. 120V-480V
1500-3000W, two
lengths; 46" & 57", Built-in Adjustable Mounting
Bracket, allows for a 45-degree tilt of the heater housing,
NEMA-4 Electrical Box and Frosted Quartz Tube. |
 |
Solaira
All Season Quartz Patio Heater.
Providing instant heat for parties, BBQs,
outdoor dining, etc.
Weatherproof - Water, snow and dust resistant construction. Includes
mounting bracket. Available in either 120 Volt, 1,200 Watt with a 16
foot cord and plug or 240 Volt, 1,300 Watt with a 14 foot cord and no
plug. |
 |
Fostoria RPH Quartz Lamp
Assembly. Restaurant patio and golf driving range heater.
Ruby Red Quartz Lamp Included. 1600 Watts (208 or 240 Volts) Single-Phase
Wiring. Optional Accessory: Wire Guard (RPHWG) 60° Symmetrical
Reflector Pattern (Coilzak Bright Aluminum Reflector) |
 |
Fostoria FFH Quartz Tube Assemblies.
Comfort spot heating with 120 volt plug and cordset. Ready
to install, just hang by its chains and plug into any 120 volt service.
Both units feature: an eight foot grounded cord set, a protective guard and gold anodized aluminum reflectors. |
 |
Fostoria Mitey Midget Quartz Lamp
Assemblies. Comfort spot heating. Indoor
industrial and commercial comfort heat applications such as: work
stations, aisleways, freezer doors, farm buildings, pump houses and
smoking shelters. Quartz lamps or tubes |
 |
Fostoria Mul-T-Mount Quartz Lamp
Assemblies. Comfort spot heating and snow melting. (208-480 volts)
3 element and 2 element Mul-T-Mount. Total Area Heating, Indoor
Spot/Zone Comfort Heating, Outdoor Spot/Zone Comfort Heating or snow &
ice control. The units are UL listed for both semi-exposed and
completely exposed outdoor areas.
|
 |
Qmark Type FRP/FRS 2 or 3
Quartz or Metal Element fixture. Total or
supplement (spot) heating in commercial and industrial areas, assembly
lines, aircraft hangers, outside smoking areas, work stations and shipping
areas. Snow melting for waiting areas and entryways, stairs, parking
lots, driveways and loading docks, smoking areas. Metal Sheath, Quartz
Tube or Quartz Lamp elements |
 |
Qmark Radiant Ceiling
Panels. Designed for installation in T-Bar ceilings
or surface or recess mounting frame kits are available. For complete or
supplemental heating in commercial, residential and institutional
structures. 24" x 24"
or 24" x 48".
Install side by side or individually above
areas requiring additional heat. |
 |
Qmark type CRN overhead washdown
120-240 Volts. Minimum mounting height: 10 feet.
Heater can be washed down after being disconnected. 90 degree
symmetrical reflector. Metal sheathed tubular heating element. Optional
accessory wire guard. |
 |
Qmark Radiant Cove Panel Heaters. 4" x 2 7/8" and length varies from
34" to 132". Convenient wall mounting near ceiling.
For supplementary heating of offices,
reception rooms, game rooms, family rooms, and similar light-duty
commercial and residential applications. |
 |
Qmark type BRM heavy duty suspended spot heater
240-600 Volts. Heaters can be suspended just like
fluorescent lighting fixtures to focus heat where desired. Designed for
heavy duty spot heating or total heating applications. Heavy duty metal
sheath heating elements. Can be operated indoors or out. Heater can be
washed down |
 |
Fostoria Heavy Duty Comfort Heating Assemblies.
120 - 600 volts. Metal sheath elements.
Fostoria Heavy Duty Infrared Heaters are for use in factories, warehouses,
maintenance areas, machine shops and any application that exposes the
fixture to shock and vibration. Fostoria's u-shaped metal sheath elements
are stable and more shock resistant than quartz lamps or tubes. |
 |
Black Body Panel Heaters.
Comfort and industrial heaters.
90% Efficient. Heavy Duty Stainless steel protective grid. Harshest
industrial environments. Available in 1, 2 and 4 feet lengths, Factories,
Workshops, Construction Sheds, Building Entrances, Loading Docks,
Warehouses, etc. |
 |
Chromalox Type SKR Comfort Heating
Assemblies 0.8 - 3.6 kW, 120, 208,
240, 275 and 480 Volt, Protective Grille, comfort heat in indoor and protected
outdoor locations. |
 |
Chromalox Type KR Spot Heating Assembly
Plug-in Single Fixed Element Radiant Heater. Comfort heat in indoor and
protected outdoor locations. Ceiling mounted by chains, steel strap or
other means. 0.8 - 1.8 kW, 120, 208 and 240 Volt , Protective Grille
|
 |
Solaira
Commercial Quartz Infrared Heater. 120 or 240
Volts. Includes
mounting bracket. 16 foot cord, with plug on 120 Volt model. 1,500 or
2,000 Watts. Instant heat
for indoor or protected outdoor uses. Metal
safety guard. |
 |
Solaira Commercial All Weather High Output Outdoor Quartz Heater.
120 or 240 Volts. Providing instant heat for
patios, restaurant outdoor dining,
driving ranges, etc. Weatherproof - Water
and snow resistant construction. Includes a 6 foot cord. No plug
included. |
 |
Solaira
Kozy Heat Quartz Heater for
outdoor/indoor covered area’s. Brackets allows vertical & horizontal
adjustment. Plug in with 15ft of cable. Ideal for
outdoor commercial areas such as Gazebos, Awnings, Open Air Terraces in
Restaurants, Clubs, Pubs and Boat Decks |
 |
Solaira Commercial High Output (HOS) 1,500
or 3,000 Watt
Indoor/Protected Outdoor Quartz Heater
designed for a wide variety of commercial, industrial and hospitality
applications: covered patio’s, under awning, windy/cold reception
area’s, zone Heating in retail, Warehouse, assembly line area, process
heating. Long life emitter (5000 hour). Available in single
or
double emitter options. 6’
of cable (no plug) |
 |
Fostoria
Trimline Quartz Tube Comfort Spot Heating Assemblies.
Comfort spot heating.
Overhead
"Spot" or "Zone" heating applications. Nearly
instantaneous heat-up and can provide heat for specific areas within a
large, open facility where a forced air heater would require more time and
energy to heat. 6' plug and cordset.
(120 & 240 Volts) |
 |
Mojave
Sun Portable 1500 Watt Infrared Pole Mount
Patio Heater. Heavy duty Offset Infrared Patio
Heater Can be used indoors and outdoors and
has wheels for easy mobility. Not for use in rain or
snow. 120 Volt. Telescopic adjustable pole. |
 |
Solaira Kozy
All Weather Quartz Heater.
120 or 240 Volts for outdoor or indoor area’s. Ideal for
outdoor commercial areas such as
Restaurants, Clubs and Pubs.
IP65 rated Rain and snow proof.
High Output, Professional Grade. 5000
hour emitter life. Tempered safety glass front.
4’ of cable (no plug). |
